Registration N9912H
In spite of the move to The Netherlands in 1990, the American registration N9912H is kept. With an American certificate and in line with the rules and regulations of the FAA (Federal Aviation Administration), as well as supported by the Stearman Restorers Association, a number of benefits do rise in the daily operation.
Preventive maintenance can be done by the owner-pilot, as approved by the FAA. The annual inspections are signed of by authorised inspectors.
Home base
The “Old Crow” flies circa 50 hours per year. Total flight time is more than 6500 hours. Home base is Lelystad Airport. This airport has a second, grass runway, which is the favourite of planes that have a tail wheel. Just “flying” is not enough for her and the Old Crow feels perfectly at home with the activities of The Storyteller.
Technische
specificaties
Aircraft
Factory
Type
Serial number
Year of construction
Registration
Origin |
: BOEING
: N-2S "Stearman"
: 75-7213
: 1943
: N9912H
: USA |
|
Equipment
Smoke system
Tow hook
Video system
Avionics
Lichting
|
: COMPRO Driftfinder
: Schweizer
: Datatoys Pro-Plus, 4 cam MPEG2 (SD card)
: 72 ch COMM, GPS, Mode S Xponder, Intercom, 243 MHz ELT
: NAV en Strobes
|
Engine
Factory
Type
Power
Cyl. content
Number cylinders
Fuel consumption |
: JACOBS
: R755B2M
: 275 pk
: 755 cu/inc (12,6 ltr)
: 7 in radial
: 52 ltr/hour |
|
Propeller
Type
Number of blades
Diameter
Material
Blades |
: Hamilton
Standard 2B20
: 2
: 2,15 mtr.
: metal
: Adjustable |
Dimensions
Span
Length
Height
Fuel quantity |
: 9,80 mtr.
: 7,50 mtr.
: 2,85 mtr.
: 150 ltr. |
|
Weights
Empty weight
Max. T/O weight
Max. landing weight
payload |
: 1025 kg
: 1275 kg
: 1275 kg
: 180 kg |
Performance
Max. cruise speed
Norm. cruis speed
Landingspeed
Max. altitude
Range |
: 95 kts (176 km/u)
: 85 kts (157 km/u)
: 65 kts (120 km/u)
: 15000 ft (4500 mtr)
: 400 km |
|
Persons
Quantity
Crew
Passenger |
: 2
: 1
: 1 |
|
|
|
|
|
|
